Titanium Circles & Rings – Precision Crafted with Polished, Pickled, and Brushed Finishes. Available in Grades 2, Gr 5, Gr 7, Gr 9, Gr 23 for High-Strength, Lightweight, and Corrosion-Resistant Components.
We are a leading manufacturer and supplier of high-quality Titanium Circles & Rings, designed to meet the demanding requirements of aerospace, chemical, marine, and medical industries. Utilizing advanced forging and precision machining techniques, our titanium products deliver excellent strength-to-weight ratio, corrosion resistance, and biocompatibility. Manufactured in accordance with international standards, our Titanium Circles & Rings guarantee superior performance and reliability for critical applications.
Our Titanium Circles & Rings are available in a wide range of sizes, with diameters from 100 mm up to 2000 mm and thicknesses ranging between 3 mm and 50 mm. Produced from commercially pure titanium grades such as Grade 1, Grade 2, Grade 5 (Ti-6Al-4V), and Grade 7, all conforming to ASTM standards like ASTM B265 and ASTM B348, ensuring consistent quality, mechanical strength, and excellent corrosion resistance. Titanium Circles & Rings are extensively used in aerospace components, chemical processing equipment, marine hardware, and medical implants due to their exceptional corrosion resistance, lightweight nature, and high strength. Their resistance to seawater and harsh chemicals makes them ideal for offshore and desalination plants, while their biocompatibility suits medical and dental applications. These circles and rings are also preferred for structural components requiring durability under extreme conditions.
Targeting key markets such as Europe, Russia, Saudi Arabia, Oman, Qatar, and the USA, we offer customized sizes, competitive pricing, and reliable delivery of Titanium Circles & Rings. Our commitment to quality and customer satisfaction ensures that our titanium products meet global standards and perform reliably in demanding applications worldwide.
Buy Precision Titanium Circles & Rings – Sizes from 2” to 60” OD, Multiple Thicknesses – Conforming to ASTM B265 & ASME SB265 Standards – Offered in Grades 2, 5, and 23 with ISO Certified Production in Forged, Rolled, and Cut Blanks.
Titanium Alloy Circles & Rings Specifications
| Product | Titanium Circles & Rings |
| Grades | Grade 1, Grade 2, Grade 3, Grade 4, Grade 5 (Ti-6Al-4V), Grade 7, Grade 9, Grade 12, Grade 23 |
| Standards | ASTM B265, ASTM F67, ASTM F136, ASME SB265 |
| Size Range |
Outer Diameter (OD): 50mm to 1500mm Inner Diameter (ID): As per requirement Thickness: 5mm to 100mm |
| Types | Forged Rings, Rolled Rings, Machined Circles, Cut Blanks |
| Surface Finish | Black, Pickled, Polished, Machined, Sand Blasted |
| Manufacturing Methods | Forging, CNC Machining, Water Jet Cutting, Plasma Cutting |
| Applications | Aerospace, Medical Implants, Marine Components, Heat Exchangers, Flange Manufacturing |
| Properties | Corrosion Resistance, Lightweight, High Strength-to-Weight Ratio, Biocompatibility |
| Certifications | ISO 9001:2015, EN 10204 3.1, NACE MR0175, PED 2014/68/EU |
Types of Titanium Circles & Rings
Blank Circles / Discs
Supplied in custom diameters and thicknesses as per client specifications.
Flange Rings
Rings used as components for flanges in piping systems, pressure vessels, etc.
Gasket Rings
Gasket Rings are Available in standard and custom sizes as per ASME or DIN specifications.
Spacer Rings
Rings used to maintain space between mechanical parts commonly used in equipment.
Washer Rings
Smaller rings used as washers for load distribution under bolts and nuts.
Split Rings
C-shaped or snap-fit rings used to hold assemblies in grooves or shafts.
Profile Cut Rings
Custom-shaped rings cut from plates using CNC, laser, or waterjet, for specific machinery.
Forged Rings
Heavy-duty rings forged for strength, used in aerospace, marine industry or heavy machinery.
Equivalent of Titanium Circles
| Grade | UNS Number | DIN | BS | ISO |
|---|---|---|---|---|
| Grade 1 | R50250 | 3.7025 | TA1 | Ti 35A |
| Grade 2 | R50400 | 3.7035 | TA2 | Ti 40 |
| Grade 3 | R50550 | 3.7055 | TA3 | Ti 55 |
| Grade 4 | R50700 | 3.7065 | TA4 | Ti 65 |
| Grade 5 (Ti-6Al-4V) | R56400 | 3.7165 | Ti6Al4V | Ti 6Al-4V |
| Grade 7 | R52400 | 3.7235 | TA7 | Ti-Pd |
| Grade 9 (Ti-3Al-2.5V) | R56320 | 3.7195 | Ti3Al2.5V | Ti 3Al-2.5V |
| Grade 11 | R52250 | 3.7225 | TA11 | Ti-Pd |
| Grade 12 | R53400 | 3.7105 | TiMoNi | Ti 0.3Mo-0.8Ni |
| Grade 23 (Ti-6Al-4V ELI) | R56401 | – | Ti6Al4V ELI | Ti 6Al-4V ELI |
Chemical Composition of Titanium Rings
| Grade | Ti | Al | V | Fe | O | C | N | H | Other |
|---|---|---|---|---|---|---|---|---|---|
| Grade 1 | ≥ 99.5% | — | — | ≤ 0.20% | ≤ 0.18% | ≤ 0.08% | ≤ 0.03% | ≤ 0.015% | ≤ 0.40% |
| Grade 2 | Balance | — | — | ≤ 0.30% | ≤ 0.25% | ≤ 0.08% | ≤ 0.03% | ≤ 0.015% | ≤ 0.40% |
| Grade 5 (Ti-6Al-4V) | Balance | 5.5 – 6.75% | 3.5 – 4.5% | ≤ 0.40% | ≤ 0.20% | ≤ 0.08% | ≤ 0.05% | ≤ 0.015% | ≤ 0.40% |
| Grade 7 | Balance | — | — | ≤ 0.30% | ≤ 0.25% | ≤ 0.08% | ≤ 0.03% | ≤ 0.015% | Pd: 0.12 – 0.25% |
| Grade 9 (Ti-3Al-2.5V) | Balance | 2.5 – 3.5% | 2.0 – 3.0% | ≤ 0.25% | ≤ 0.15% | ≤ 0.08% | ≤ 0.03% | ≤ 0.015% | ≤ 0.40% |
| Grade 12 | Balance | — | — | ≤ 0.30% | ≤ 0.25% | ≤ 0.08% | ≤ 0.03% | ≤ 0.015% | Mo: 0.2–0.4%, Ni: 0.6–0.9% |
| Grade 23 (Ti-6Al-4V ELI) | Balance | 5.5 – 6.5% | 3.5 – 4.5% | ≤ 0.25% | ≤ 0.13% | ≤ 0.08% | ≤ 0.03% | ≤ 0.0125% | ≤ 0.40% |
Mechanical Properties of Titanium Circles & Rings
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (Rockwell) | Modulus of Elasticity (GPa) |
|---|---|---|---|---|---|
| Grade 1 | 240 min | 170 min | 24 | Rin 70–80 | 105 |
| Grade 2 | 345 min | 275 min | 20 | Rin 70–80 | 105 |
| Grade 3 | 450 min | 380 min | 18 | Rin 80–90 | 105 |
| Grade 4 | 550 min | 480 min | 15 | Rin 90–95 | 105 |
| Grade 5 (Ti-6Al-4V) | 895 min | 828 min | 10 | Rin 36–41 | 113.8 |
| Grade 7 | 345 min | 275 min | 20 | Rin 70–80 | 105 |
| Grade 9 (Ti-3Al-2.5V) | 620 min | 483 min | 15 | Rin 20–30 | 105 |
| Grade 11 | 240 min | 170 min | 24 | Rin 70–80 | 105 |
| Grade 12 | 483 min | 345 min | 18 | Rin 70–80 | 105 |
| Grade 23 (Ti-6Al-4V ELI) | 860 min | 795 min | 10 | Rin 36–41 | 113.8 |
Dimension Chart of Titanium Alloy Circles
| Outer Diameter (OD) | Thickness (mm) | Approx. Weight (kg) | Available Grades |
|---|---|---|---|
| 50 mm | 5 – 20 mm | 0.8 – 3.2 | Grade 2, Grade 5 |
| 100 mm | 5 – 30 mm | 3.2 – 10.5 | Grade 2, Grade 5, Grade 23 |
| 200 mm | 5 – 50 mm | 8.5 – 42.0 | Grade 2, Grade 5 |
| 500 mm | 10 – 60 mm | 35 – 150 | Grade 2, Grade 5, Grade 7 |
| 1000 mm | 15 – 80 mm | 130 – 400 | Grade 5, Grade 23 |
| 1500 mm | 20 – 100 mm | 310 – 750 | Grade 5 |
Pure Titanium Rings Weight Chart
| Thickness (mm) | Diameter (mm) | Weight (kg) | Weight (lbs) |
|---|---|---|---|
| 3 | 100 | 2.47 | 5.44 |
| 5 | 150 | 5.63 | 12.41 |
| 7 | 200 | 10.92 | 24.08 |
| 10 | 250 | 16.36 | 36.06 |
| 15 | 300 | 24.50 | 54.01 |
| 20 | 350 | 34.36 | 75.70 |
| 25 | 400 | 46.18 | 101.06 |
| 30 | 450 | 59.80 | 131.43 |
