ISO Certified Carbon Steel Plates & Coils – Offered in A285 Gr C, A515 Gr 60/70, IS 2062 E250/E350, EN S275JR, S355J2 Grades with Hot Rolled & Cold Rolled Finishes, Available in Mill Edge, Sheared Edge & Custom Profiles.

We are a reliable manufacturer, supplier, and exporter of high-quality Carbon Steel Plates, Sheets, and Coils, known for their outstanding strength, durability, and cost-efficiency. Designed to meet the diverse needs of modern industries, our carbon steel products deliver excellent mechanical performance in both standard and demanding environments. We offer a comprehensive range of grades including ASTM A36, A516 Grade 60, 70, IS 2062, EN 10025, EN-8, EN 47, EN-19, EN-42 J, C-70, C-80, ASTM A283, A572, A537 and other internationally recognized specifications. These materials are extensively used in construction, infrastructure, pressure vessels, general engineering, and heavy equipment manufacturing due to their high load-bearing capacity and structural integrity.

Our product range includes hot-rolled plates, cold-rolled sheets, and high-precision coils available in various surface finishes such as HR, CR, shot blasted, pickled, and oiled. These carbon steel materials are available in multiple dimensions with thicknesses ranging from 1 mm to 150 mm, widths up to 3000 mm, and lengths customizable as per project-specific needs. All products are manufactured using advanced techniques like hot rolling, cold rolling, and precision leveling, followed by accurate cutting methods including plasma cutting, laser cutting, and shearing to ensure tight dimensional tolerances and clean finishes.

Carbon Steel Plates are well-suited for use in structural frameworks, shipbuilding, general fabrication, tanks, boilers, pipelines, and heavy equipment manufacturing. Known for their excellent weldability, machinability, and toughness, these materials perform reliably under dynamic loading and harsh working conditions. For pressure-retaining and load-bearing applications, our plates meet international standards such as ASTM, ASME, EN, IS, and DIN, and are supplied with certifications in line with ISO 9001:2015, IBR, and PED requirements to ensure quality and traceability.

Whether your requirement is for stock sizes or tailored solutions, we offer a wide inventory and flexible supply chain to meet urgent and bulk demands. With a focus on quality assurance, timely delivery, and competitive pricing, we serve industries including oil & gas, construction, power generation, transportation, and fabrication across domestic and international markets. Our commitment to excellence makes us a reliable partner for all your Carbon Steel Plate, Sheet, and Coil needs.

Extensive Range of Carbon Steel Plates, Sheets & Coils – Hot Rolled Plates, Cold Rolled Sheets, Galvanized Coils, Chequered Sheets, HRPO & CRCA – Thickness from 1.5mm to 150mm, Widths up to 3000mm, ASTM A36, A516, IS 2062 Certified.

Carbon Steel Sheets Specifications

Parameter Specification
Grades ASTM A36, A283 Gr C, A516 Gr 60/70, A515 Gr 60/70, A572 Gr 50, A285 Gr C, A537 Cl 1,
IS 2062 E250/E275/E350, EN 10025 S235JR/S275JR/S355JR/S355J2, EN 10028 P265GH/P355GH
Standards ASTM, ASME, IS, EN, DIN, JIS (as applicable to the grade)
Thickness Range 1.5 mm to 150 mm
Width Range 1000 mm to 3000 mm
Length Up to 12000 mm or customized
Form Hot Rolled (HR), Cold Rolled (CR)
Surface Finish Black, Bright, Pickled, Shot Blasted, Oiled
Edge Condition Mill Edge, Sheared Edge
Certification EN 10204 3.1 / 3.2, ISO 9001:2015, IBR (if applicable)
Applications Pressure Vessels, Boilers, Structural Steel, Oil & Gas, Marine, Construction, Bridges, General Engineering

Types of Carbon Steel Plates, Sheet, Coils

Shim Sheets

Shim Sheets built for high performance, reliability, and precision engineering.

Perforated Sheet

Perforated Metal Sheets built for performance and modern design solutions.

Chequered Plate

Chequered Plates perfect for walkways, stairs, and safety flooring solutions.

Plain Sheet

Sturdy, smooth, and flexible – Plain Sheets for easy fabrication, welding, and industrial use.

Foils

Foils built for sensitive and high-temperature environments.

Strip

Strips offering excellent formability for a wide range of manufacturing needs.

Clad Plate

Clad Plates ideal for demanding applications requiring both strength and resistance.

Hot Rolled Plate

Rugged, tough, and reliable – Hot Rolled Plates offering exceptional toughness and performance.

Equivalent of Carbon Steel Plates

ASTM EN IS (India) DIN (Germany) JIS (Japan)
A36 S235JR IS 2062 E250 St37-2 SS400
A283 Gr C S235J0 IS 2062 E250C St44-2 SPHC
A516 Gr 60 P265GH IS 2002 Grade 1 17Mn4 SB410
A516 Gr 70 P355GH IS 2002 Grade 2 19Mn6 SB450
A515 Gr 70 IS 2002 Grade 3
A537 Cl 1
A572 Gr 50 S355JR / S355JO IS 2062 E350 St52-3 SM490A
A709 Gr 50 S355J2+N IS 2062 E350C St52-3N SM490YB
A285 Gr C P265NB SB450

Chemical Composition of Carbon Steel Coils

Grade Carbon (C) Manganese (Mn) Phosphorus (P) Sulfur (S) Silicon (Si) Other Elements
ASTM A36 ≤ 0.26% 0.60–0.90% ≤ 0.04% ≤ 0.05% ≤ 0.40%
IS 2062 (E250) ≤ 0.23% 0.90–1.50% ≤ 0.045% ≤ 0.045% ≤ 0.40%
EN 10025 S235JR ≤ 0.17% ≤ 1.40% ≤ 0.035% ≤ 0.035% ≤ 0.50%
EN 10025 S275JR ≤ 0.21% ≤ 1.50% ≤ 0.035% ≤ 0.035% ≤ 0.50%
EN 10025 S355JR ≤ 0.24% ≤ 1.60% ≤ 0.035% ≤ 0.035% ≤ 0.55%
EN 10025 S355J2 ≤ 0.20% ≤ 1.60% ≤ 0.030% ≤ 0.030% ≤ 0.55% Charpy V-notch @ -20°C
ASTM A516 Gr 70 ≤ 0.27% 0.79–1.30% ≤ 0.035% ≤ 0.035% 0.13–0.45%
SA 283 Gr C ≤ 0.24% 0.90–1.20% ≤ 0.035% ≤ 0.035%
ASTM A515 Gr 70 ≤ 0.35% 0.60–1.00% ≤ 0.035% ≤ 0.035% 0.15–0.35%
SA 537 CL 1 ≤ 0.24% 0.70–1.60% ≤ 0.035% ≤ 0.035% 0.13–0.45%

Mechanical Properties of CS Sheets

Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation (%) Impact Energy
ASTM A36 ≥ 250 400–550 20
IS 2062 E250 ≥ 250 410–540 23
EN 10025 S235JR ≥ 235 360–510 26 27 J @ +20°C
EN 10025 S275JR ≥ 275 370–530 23 27 J @ +20°C
EN 10025 S355JR ≥ 355 470–630 22 27 J @ +20°C
EN 10025 S355J2 ≥ 355 470–630 22 27 J @ –20°C
ASTM A516 Gr 70 ≥ 260 485–620 21
ASTM A515 Gr 70 ≥ 260 485–655 19
SA 283 Gr C ≥ 205 380–515 20
SA 537 Cl 1 ≥ 345 485–620 22 Charpy Impact Tested

Gauge Thickness of Carbon Steel Plates, Sheet, Coils

Thickn inches. lbs. per sq. ft. Thick inch lbs. per sq. ft.
Total Range
Gage No. Dec. Equiv. H.R. & P. & O Cold Rolled Wt. Equiv. Gage No. Dec. Equiv. Total. Range C.R. Weight. Equiv.
5 .2092 .2182 .2002 8.75 20 .0359 .0389 .0329 1.5
4 .2242 .2332 .2152 9.375 19 .0418 .0458 .0378 1.75
7 .1793 .1873 .1713 .1883 .1703 7.5 22 .0299 .0329 .0269 1.25
6 .1943 .2033 .1853 8.125 21 .0329 .0359 .0299 1.375
9 .1495 .1575 .1415 .1585 .1405 6.25 24 .0239 .0269 .0209 1.0
8 .1644 .1724 .1564 .1734 .1554 6.875 23 .0269 .0299 .0239 1.125
11 .1196 .1276 .1116 .1256 .1136 5.0 26 .0179 .0199 .0159 .75
10 .1345 .1425 .1265 .1405 .1285 5.625 25 .0209 .0239 .0179 .875
13 .0897 .0967 .0827 .0947 .0847 3.75 28 .0149 .0169 .0129 .625
15 .0673 .0733 .0613 .0723 .0623 2.812 30 .0120 .0130 .0110 .50
12 .1046 .1126 .0966 .1106 .0986 4.375 27 .0164 .0184 .0144 .688
14 .0747 .0817 .0677 .0797 .0697 3.125 29 .0135 .0155 .0115 .562

Carbon Steel Plates Weight Chart

Thickness (mm) Weight per Square Meter (kg/m²)
1.07.85
1.511.78
2.015.70
2.519.63
3.023.55
4.031.40
5.039.25
6.047.10
8.062.80
10.078.50
12.094.20
16.0125.60
20.0157.00
25.0196.25
30.0235.50
40.0314.00
50.0392.50
60.0471.00
80.0628.00
100.0785.00
