Industrial Grade Brass Circles & Rings – Polished, Brushed & Custom Machined Blanks – Available in Free-Cutting C36000, Cartridge C26000, and Naval Brass C46400 – Standards Include ASTM B36 & ASTM B171.
We are a reliable and ISO 9001:2015 certified manufacturer and exporter of Brass Circles & Rings, offering high-precision components tailored for various sectors including electrical, plumbing, automotive, and decorative industries. These products are manufactured using top-grade raw materials and advanced forming processes, ensuring dimensional accuracy, surface finish, and long-term durability. Our production complies with international quality norms and is backed by mill test certificates (MTC), third-party inspection, and full traceability.
Our Brass Circles & Rings are available in various types such as hot-rolled, cold-rolled, and forged rings, in sizes ranging from 50 mm to 1500 mm diameter and 3 mm to 50 mm thickness. We offer a wide selection of grades including C26000 (Cartridge Brass), C28000 (Muntz Metal), C36000 (Free-Cutting Brass), and C46400 (Naval Brass). These conform to ASTM B36 and ASTM B16 standards. Chemically, brass typically contains 60–70% copper and 30–40% zinc, with mechanical properties including tensile strength of 300–550 MPa, elongation up to 45%, and good hardness depending on temper (soft, half-hard, or hard condition).
Known for excellent machinability, corrosion resistance, and aesthetic appearance, Brass Circles & Rings are widely used in marine fittings, gear components, valves, musical instruments, and architectural hardware. Their high thermal and electrical conductivity, combined with easy formability and polishing capabilities, make them ideal for both functional and decorative use. We cater to global markets with certified quality, competitive pricing, custom size solutions, and on-time delivery.
High-Precision Red Brass, Yellow Brass Circles & Rings – Forged, Machined & Rolled Options Available – Soft to Hard Tempers – OD Range: 10mm–1500mm, Thickness: 1mm–100mm – Ideal for Industrial and Decorative Use.
Brass Circles & Rings Specifications
| Product | Brass Circles & Rings |
| Grades | C260 (Cartridge Brass), C464 (Naval Brass), C360 (Free-Cutting Brass), C272 (Yellow Brass) |
| Standards | ASTM B36, ASTM B171, ASTM B122, ASTM B124 |
| Size Range | Outer Diameter (OD): 10mm to 1500mm Inner Diameter (ID): As per requirement Thickness: 1mm to 100mm |
| Types | Forged Rings, Rolled Rings, Machined Circles, Cut Blanks |
| Surface Finish | Polished, Brushed, Matte, Bright, Custom Finishes |
| Manufacturing Methods | Forging, CNC Machining, Water Jet Cutting, Plasma Cutting, Punching |
| Applications | Architectural Hardware, Marine Parts, Decorative Items, Electrical Components, Industrial Bushings |
| Properties | Good Corrosion Resistance, Excellent Machinability, High Electrical Conductivity, Attractive Appearance |
| Certifications | ISO 9001:2015, EN 10204 3.1, RoHS Compliant |
Types of Brass Circles & Rings
Blank Circles / Discs
Supplied in custom diameters and thicknesses as per client specifications.
Flange Rings
Rings used as components for flanges in piping systems, pressure vessels, etc.
Gasket Rings
Gasket Rings are Available in standard and custom sizes as per ASME or DIN specifications.
Spacer Rings
Rings used to maintain space between mechanical parts commonly used in equipment.
Washer Rings
Smaller rings used as washers for load distribution under bolts and nuts.
Split Rings
C-shaped or snap-fit rings used to hold assemblies in grooves or shafts.
Profile Cut Rings
Custom-shaped rings cut from plates using CNC, laser, or waterjet, for specific machinery.
Forged Rings
Heavy-duty rings forged for strength, used in aerospace, marine industry or heavy machinery.
Equivalent of Brass Alloy Circles
| UNS / ASTM Grade | EN / BS (Europe / UK) | JIS (Japan) | DIN (Germany) | Common Name |
|---|---|---|---|---|
| C21000 | CuZn5 / CW500L | C2100 | 2.0230 | Gilding Metal |
| C22000 | CuZn15 / CW501L | C2200 | 2.0240 | Commercial Bronze |
| C23000 | CuZn15 / CW502L | C2300 | 2.0250 | Red Brass |
| C24000 | CuZn20 / CW503L | – | 2.0260 | Low Brass |
| C26000 | CuZn30 / CW505L | C2600 | 2.0265 | Cartridge Brass |
| C26800 | CuZn33 / CW506L | C2680 | 2.0280 | Yellow Brass |
| C27200 | CuZn36 / CW507L | C2720 | 2.0290 | Valley Forge Brass |
| C28000 | CuZn40 / CW509L | C2801 | 2.0300 | Muntz Metal |
| C33000 | CuZn35Pb1 / CW608N | – | – | Low Leaded Brass |
| C35300 | CuZn36Pb1.5 / CW614N | – | 2.0380 | High Leaded Brass |
| C36000 | CuZn36Pb3 / CW603N | C3601 | 2.0401 | Free Cutting Brass |
| C46400 | CuZn39Sn / CW712R | – | 2.0460 | Naval Brass |
| C48500 | – | – | – | High Leaded Naval Brass |
| – | CZ108 | – | 2.0321 | Brass Sheet (CuZn37) |
| – | CZ109 | – | 2.0321 | General Engineering Brass |
| – | CZ110 | – | – | Lead Free Brass |
| – | CZ121 | – | 2.0401 | Free Machining Brass |
Chemical Composition of Red Brass Rings
| Grade | Copper (Cu) | Zinc (Zn) | Lead (Pb) | Tin (Sn) | Iron (Fe) | Others |
|---|---|---|---|---|---|---|
| C21000 (Gilding Metal) | 95.0 – 97.0% | Remainder | 0.05% max | – | 0.05% max | – |
| C22000 (Commercial Bronze) | 90.0% | Remainder | 0.05% max | – | 0.05% max | – |
| C23000 (Red Brass) | 85.0% | Remainder | 0.05% max | – | 0.05% max | – |
| C26000 (Cartridge Brass) | 68.5 – 71.5% | Remainder | 0.07% max | – | 0.05% max | – |
| C26800 (Yellow Brass) | 66.0 – 69.0% | Remainder | 0.09% max | – | 0.05% max | – |
| C27200 (Valley Forge Brass) | 62.0 – 65.0% | Remainder | 0.07% max | – | 0.05% max | – |
| C28000 (Muntz Metal) | 59.0 – 63.0% | Remainder | 0.07% max | – | 0.05% max | – |
| C33000 (Low Leaded Brass) | 65.0 – 68.5% | Remainder | 0.5 – 1.5% | – | 0.05% max | – |
| C35300 (High Leaded Brass) | 61.5 – 64.5% | Remainder | 1.5 – 2.5% | – | 0.10% max | – |
| C36000 (Free Cutting Brass) | 60.0 – 63.0% | Remainder | 2.5 – 3.7% | – | 0.35% max | – |
| C46400 (Naval Brass) | 59.0 – 62.0% | Remainder | 0.3% max | 0.9 – 1.2% | 0.06% max | – |
| C48500 (High Leaded Naval Brass) | 56.0 – 59.0% | Remainder | 1.5 – 2.5% | 0.5 – 1.2% | 0.06% max | – |
Mechanical Properties of Brass Alloy Circles & Rings
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HRB) | Modulus of Elasticity (GPa) |
|---|---|---|---|---|---|
| C21000 (Gilding Metal) | 275 – 345 | 70 – 100 | 45 – 50 | 45 – 65 | 110 |
| C22000 (Commercial Bronze) | 310 – 410 | 80 – 130 | 40 – 50 | 50 – 70 | 110 |
| C23000 (Red Brass) | 345 – 415 | 100 – 140 | 35 – 45 | 60 – 80 | 110 |
| C26000 (Cartridge Brass) | 315 – 500 | 95 – 210 | 15 – 45 | 55 – 80 | 110 |
| C26800 (Yellow Brass) | 345 – 520 | 100 – 240 | 15 – 40 | 60 – 85 | 110 |
| C27200 (Valley Forge Brass) | 350 – 530 | 110 – 250 | 15 – 35 | 65 – 90 | 110 |
| C28000 (Muntz Metal) | 365 – 540 | 120 – 260 | 12 – 30 | 70 – 95 | 110 |
| C33000 (Low Leaded Brass) | 310 – 450 | 90 – 180 | 20 – 40 | 60 – 80 | 110 |
| C35300 (High Leaded Brass) | 365 – 510 | 100 – 200 | 15 – 30 | 70 – 90 | 110 |
| C36000 (Free Cutting Brass) | 415 – 585 | 125 – 250 | 5 – 25 | 80 – 100 | 110 |
| C46400 (Naval Brass) | 395 – 585 | 140 – 270 | 10 – 30 | 70 – 95 | 110 |
| C48500 (High Leaded Naval Brass) | 410 – 600 | 140 – 280 | 10 – 25 | 75 – 100 | 110 |
Dimension Chart of Naval Brass Circles
| Outer Diameter (OD) | Inner Diameter (ID) | Thickness | Approximate Weight (grams) |
|---|---|---|---|
| 10 mm | 8 mm | 0.3 mm | 0.12 g |
| 10 mm | 8 mm | 0.5 mm | 0.20 g |
| 20 mm | 18 mm | 0.3 mm | 0.48 g |
| 20 mm | 18 mm | 0.5 mm | 0.80 g |
| 30 mm | 28 mm | 0.3 mm | 0.96 g |
| 30 mm | 28 mm | 0.5 mm | 1.60 g |
| 40 mm | 38 mm | 0.3 mm | 1.68 g |
| 40 mm | 38 mm | 0.5 mm | 2.80 g |
| 50 mm | 48 mm | 0.3 mm | 2.40 g |
| 50 mm | 48 mm | 0.5 mm | 4.00 g |
| 60 mm | 58 mm | 0.3 mm | 3.36 g |
| 60 mm | 58 mm | 0.5 mm | 5.60 g |
| 70 mm | 68 mm | 0.3 mm | 4.64 g |
| 70 mm | 68 mm | 0.5 mm | 7.70 g |
| 80 mm | 78 mm | 0.3 mm | 6.00 g |
| 80 mm | 78 mm | 0.5 mm | 10.00 g |
| 90 mm | 88 mm | 0.3 mm | 7.56 g |
| 90 mm | 88 mm | 0.5 mm | 12.60 g |
| 100 mm | 98 mm | 0.3 mm | 9.24 g |
| 100 mm | 98 mm | 0.5 mm | 15.40 g |
Brass Rings Weight Chart
| Outer Diameter (mm) | Thickness (mm) | Approx. Weight (kg) |
|---|---|---|
| 50 | 5 | 0.083 |
| 100 | 5 | 0.334 |
| 150 | 5 | 0.752 |
| 200 | 5 | 1.337 |
| 250 | 5 | 2.086 |
| 300 | 5 | 3.009 |
| 400 | 5 | 5.348 |
| 500 | 5 | 8.351 |
| 600 | 5 | 12.018 |
| 700 | 5 | 16.349 |
| 800 | 5 | 21.344 |
| 900 | 5 | 27.004 |
| 1000 | 5 | 33.328 |
