Leading Aluminium 6061-T6 Centerless Ground Round Bars Supplier, ASTM B211 Aluminium 7075 Cold Rolled Round Bar, Aluminum 5052 Round Bar Stock Dia 3-450mm, Aluminum Round Bar Standard lengths of 2000 mm up to 6000 mm.
We are a leading manufacturer, supplier, and exporter of Aluminum Round Bars, which are solid cylindrical rods made from high-quality aluminum alloys. These bars are widely used across various industries due to their excellent strength-to-weight ratio, corrosion resistance, and durability. We manufacture our aluminum bars through a precise process that includes melting pure aluminum ingots, casting them into billets, and then extruding or rolling them into round shapes. Post-processing steps such as heat treatment and surface finishing are applied to enhance their mechanical properties and appearance, making them suitable for critical engineering applications.
The material composition of our aluminum round bars varies depending on the alloy grade, such as 6061, 6082, or 7075. For instance, 6061 contains aluminum with magnesium and silicon, offering a great balance of strength and weldability, while 7075 includes zinc and copper for high-strength applications. We supply bars in a wide range of UNS alloy designations including A91060, A91100, A92011, A92014, A92017, A92024, A92219, A93003, A95052, A95056, A95154, A96061, A96110, A96262, and A97075. These bars are available in various diameters and lengths, typically ranging from 6mm to over 300mm. Common temper conditions include O, H14, H18, H12, H16, H112, F, T3, T4, T42, T451, T6, T62, T651, T36, T351, T851, H32, H34, H36, H38, H111, H192, H392, T89, T94, T9, T73, and T7351. Technical specifications include tensile strength ranging from 150 MPa to 570 MPa, elongation from 8% to 20%, and a density of 2.7 g/cm³.
As a trusted exporter and supplier, we cater to a wide range of industries including automotive, aerospace, construction, marine, electrical, and general engineering. Our aluminum round bars are used to manufacture shafts, fasteners, frames, structural components, and conductive bus bars. Their non-magnetic and non-sparking nature makes them ideal for specialized applications in sensitive environments. With their versatility and ease of fabrication, our aluminum bars are a preferred choice for both standard and customized engineering requirements.
The key advantages of using our aluminum round bars include their lightweight nature, excellent corrosion resistance, high machinability, and recyclability. They also offer good thermal and electrical conductivity, while their dimensional accuracy ensures consistent and reliable performance. Available in various surface finishes such as mill finish, polished, or anodized, our aluminum bars comply with international quality standards and undergo rigorous quality control checks. Whether for industrial, structural, or precision engineering use, MSTAR ENTERPRISES's aluminum round bars deliver unmatched performance and long-term value.
Get Aluminum Hot Rolled Bar With Size Range is as Per Client Requirement, Ready Stock Of Aluminum 1060, 1100, 2014 T6, 2024, 5052, 6063 T6, 6360 – Available in Custom Lengths Up to 12m.
Aluminum Round Bars Specifications
Grades | ALUMINIUM 6061, 6063, 6064, 6082, 5083, 5086, 5052, 7075, 1100 |
---|---|
Specification | ASTM B211, AMS 4115, 4116, 4117, 4128, AMS-QQ-A-225/8 & ASTM B221, AMS4150, 4160, 4161, AMS-QQ-A-200/8 |
Dimensions | EN, ASME, AISI, DIN, JIS, ASTM, BS |
Round Bar size | Diameter: 3-~800mm |
Square bar size | 4 to 100mm |
Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
Hex Bar size | 2-100mm A/F |
Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
Rectangles Size | 33 x 30mm to 295 x 1066mm |
Flat bar size | Thickness: 2 -100mm |
Width: 10 to 500mm | |
Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
Aluminium Section | 3.0 to 12.0mm thickness |
Billet Size | 1/2″ to 495mm Diameter |
Round Bar Standard Dimensions | Diameter / Height: Aluminium Rod and Bar Sizes : 0.5 inches / 0.625 inches / 0.75 inches / 0.875 inches / 1.0 inches / 1.125 inches / 1.25 inches / 1.375 inches / 1.5 inches / 1.75 inches / 2.0 inches / 2.25 inches / 2.5 inches / 2.75 inches / 3.0 inches / 3.25 inches / 3.5 inches / 3.75 inches / 4.0 inches / 4.25 inches / 4.5 inches / 5.0 inches / 5.25 inches / 5.5 inches / 6.0 inches / 7.0 inches / 8.0 inches / 9.0 inches. |
Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
Technique | Aluminium Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
Condition | Hardened & tempered, annealed |
Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
Form | Aluminium Round, Rod, Square Bars, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square Bar, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
Processing | Bar cutting to 650mm |
Our Aluminium Round bar conforms to NACE MR0175/ISO 15156 |
Types of Aluminum Round Bars
Hot Rolled Round Bars
Manufactured by hot rolling, offering excellent strength and durability.
Cold Drawn Round Bars
Precision-made with a smooth surface finish, ideal for machining.
Peeled & Polished Round Bars
Enhanced surface finish with high dimensional accuracy
Centerless Ground Round Bars
Extremely precise tolerance with a fine, smooth surface.
Forged Round Bars
High-strength bars for heavy-duty industrial applications.
Bright Round Bars
High-quality, smooth surface bars used in precision applications.
Black Round Bars
Raw, unfinished bars used in industrial applications requiring further processing.
Equivalent of Aluminum Round Bars
Aluminum Alloy | UNS Number | ASTM/AMS | ISO | EN (AW) | BS | JIS | DIN |
---|---|---|---|---|---|---|---|
1060 | A91060 | ASTM B211 | Al99.6 | EN AW-1060 | 1B | A1050 | 3.0255 |
1100 | A91100 | ASTM B211 | Al99.0 | EN AW-1100 | 1A | A1100 | 3.0255 |
2011 | A92011 | ASTM B211 | AlCu6BiPb | EN AW-2011 | H14 | 2011 | 3.1655 |
2014 | A92014 | ASTM B211 | AlCu4SiMg | EN AW-2014 | 24345 | 2014 | 3.1255 |
2024 | A92024 | ASTM B211 | AlCu4Mg1 | EN AW-2024 | L97 | 2024 | 3.1355 |
2219 | A92219 | ASTM B211 | AlCu6Mn | EN AW-2219 | 2219 | 3.1354 | |
3003 | A93003 | ASTM B211 | AlMn1Cu | EN AW-3003 | H12 | 3003 | 3.0517 |
5052 | A95052 | ASTM B211 | AlMg2.5 | EN AW-5052 | H32 | 5052 | 3.3523 |
5056 | A95056 | ASTM B211 | AlMg5Mn | EN AW-5056 | 5056 | 3.3555 | |
5154 | A95154 | ASTM B211 | AlMg3.5 | EN AW-5154 | 5154 | 3.3535 | |
6061 | A96061 | ASTM B221 / AMS 4117 | AlMg1SiCu | EN AW-6061 | H20 | 6061 | 3.3211 |
6082 | — | ASTM B221 | AlSi1MgMn | EN AW-6082 | HE30 | 6082 | 3.2315 |
6262 | A96262 | ASTM B221 | AlMgSiPb | EN AW-6262 | 6262 | 3.1645 | |
7075 | A97075 | ASTM B211 / AMS 4045 | AlZn5.5MgCu | EN AW-7075 | L160 | 7075 | 3.4365 |
Chemical Composition of Aluminum Round Bars
Aluminum Grade | Al (Min%) | Si (%) | Fe (%) | Cu (%) | Mn (%) | Mg (%) | Cr (%) | Zn (%) | Ti (%) | Other (%) |
---|---|---|---|---|---|---|---|---|---|---|
1060 | 99.60 | 0.25 max | 0.35 max | 0.05 max | 0.03 max | 0.03 max | — | 0.05 max | 0.03 max | 0.15 max |
1100 | 99.00 | 0.95 max | 0.95 max | 0.05–0.20 | 0.05 max | 0.05 max | — | 0.10 max | 0.05 max | 0.15 max |
2011 | — | 0.40–0.80 | 0.70 max | 5.0–6.0 | 0.20 max | 0.20 max | — | 0.30 max | 0.08 max | Bi + Pb 0.6–1.2 |
2024 | — | 0.50 max | 0.50 max | 3.8–4.9 | 0.30–0.9 | 1.2–1.8 | 0.10 max | 0.25 max | 0.15 max | 0.15 max |
5052 | — | 0.25 max | 0.40 max | 0.10 max | 0.10 max | 2.2–2.8 | 0.15–0.35 | 0.10 max | 0.05 max | 0.15 max |
6061 | — | 0.40–0.80 | 0.70 max | 0.15–0.40 | 0.15 max | 0.8–1.2 | 0.04–0.35 | 0.25 max | 0.15 max | 0.15 max |
6082 | — | 0.70–1.3 | 0.50 max | 0.10 max | 0.40–1.0 | 0.6–1.2 | 0.25 max | 0.20 max | 0.10 max | 0.15 max |
7075 | — | 0.40 max | 0.50 max | 1.2–2.0 | 0.30 max | 2.1–2.9 | 0.18–0.28 | 5.1–6.1 | 0.20 max | 0.15 max |
Mechanical Properties of Aluminum Round Bars
Aluminum Grade | Temper | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (Brinell HB) |
---|---|---|---|---|---|
1060 | O | 60–95 | 25–30 | 25–35 | 20 |
1100 | H14 | 110–150 | 95–125 | 5–10 | 35 |
2011 | T3 | 340–390 | 275–345 | 10–15 | 95 |
2024 | T4 | 470 | 325 | 20 | 120 |
5052 | H32 | 210–260 | 130–195 | 12–20 | 65 |
6061 | T6 | 310–350 | 270–310 | 10–17 | 95 |
6082 | T6 | 310–340 | 260–300 | 8–12 | 95 |
7075 | T6 | 510–570 | 430–480 | 7–11 | 150 |
Sizes Chart of Aluminum Round Bars
Diameter (mm) | Inch Equivalent | Available Length (meters) | Standard Tolerance |
---|---|---|---|
3 mm | 1/8″ | 1 – 6 m | ±0.10 mm |
6 mm | 1/4″ | 1 – 6 m | ±0.10 mm |
10 mm | 3/8″ | 1 – 6 m | ±0.15 mm |
12 mm | 1/2″ | 1 – 6 m | ±0.15 mm |
16 mm | 5/8″ | 1 – 6 m | ±0.20 mm |
20 mm | 3/4″ | 1 – 6 m | ±0.20 mm |
25 mm | 1″ | 1 – 6 m | ±0.25 mm |
40 mm | 1-9/16″ | 1 – 6 m | ±0.30 mm |
50 mm | 2″ | 1 – 6 m | ±0.35 mm |
100 mm | 4″ | 1 – 6 m | ±0.50 mm |
150 mm | 6″ | 1 – 6 m | ±0.75 mm |
200 mm | 8″ | 1 – 6 m | ±1.00 mm |
Aluminum Round Bar Weight Per Foot
Round Bar | ||||||||
---|---|---|---|---|---|---|---|---|
Size | Kgs / Foot | Kgs / Mtr | Size | Kgs / Foot | Kgs / Mtr | Size | Kgs / Foot | Kgs / Mtr |
3mm | 0.017 | 0.055 | 20milimeter | 0.753 | 2.470 | 3" | 10.900 | 35.762 |
1/8" | 0.019 | 0.062 | 22milimeter | 0.908 | 2.979 | 3-1/4" | 12.800 | 41.996 |
5/32" | 0.029 | 0.095 | 7/8" | 0.926 | 3.038 | 3-1/2" | 14.850 | 48.772 |
4mm | 0.030 | 0.098 | 24milimeter | 1.080 | 3.543 | 3-3/4" | 17.001 | 55.780 |
3/16" | 0.043 | 0.141 | 25mm | 1.180 | 3.871 | 4" | 19.306 | 63.340 |
5milimeter | 0.047 | 0.154 | 1" | 1.210 | 3.970 | 4-1/4" | 21.908 | 72.249 |
7/32" | 0.058 | 0.190 | 26mm | 1.271 | 4.170 | 4-1/2" | 24.4487 | 80.340 |
6mm | 0.068 | 0.223 | 27mm | 1.368 | 4.490 | 4-3/4" | 27.366 | 90.249 |
1/4" | 0.076 | 0.249 | 1-1/8" | 1.534 | 5.033 | 5" | 30.461 | 99.940 |
7 | 0.091 | 0.298 | 30milimeter | 1.691 | 5.548 | 5-1/2" | 36.690 | 121.000 |
5/16" | 0.118 | 0.387 | 1-1/4" | 1.924 | 6.349 | 6" | 43.860 | 143.900 |
8 | 0.120 | 0.398 | 32 | 1.894 | 6.314 | 6-1/2" | 51.093 | 167.630 |
9mm | 0.152 | 0.498 | 1-3/8" | 2.303 | 7.550 | 7" | 59.432 | 196.000 |
3/8" | 0.170 | 0.557 | 35 | 2.390 | 7.553 | 7-1/2" | 68.226 | 225.000 |
10mm | 0.189 | 0.620 | 36mm | 2.438 | 7.999 | 8" | 77.586 | 254.55 |
11mm | 0.228 | 0.748 | 38 | 2.792 | 8.903 | 10" | 121.048 | 397.140 |
7/16" | 0.232 | 0.761 | 1-1/2" | 2.715 | 8.951 | |||
12mm | 0.271 | 0.889 | 40mm | 3.009 | 9.872 | |||
1/2" | 0.303 | 0.994 | 1-5/8" | 3.200 | 10.449 | |||
13mm | 0.318 | 1.043 | 1-3/4" | 3.712 | 12.179 | |||
14mm | 0.368 | 1.207 | 45mm | 3.807 | 12.555 | |||
9/16" | 0.383 | 1.256 | 1-7/8" | 4.260 | 13.977 | |||
15mm | 0.424 | 1.391 | 48mm | 4.330 | 14.205 | |||
5/8" | 0.473 | 1.551 | 50mm | 4.698 | 15.414 | |||
16mm | 0.481 | 1.578 | 2" | 4.848 | 15.906 | |||
17mm | 0.543 | 1.791 | 2-1/8" | 5.475 | 17.963 | |||
11/16" | 0.573 | 1.880 | 2-1/4" | 6.135 | 20.128 | |||
18mm | 0.610 | 2.001 | 60mm | 6.768 | 22.205 | |||
3/4" | 0.682 | 2.237 | 2-3/8" | 6.838 | 22.435 | |||
2-1/2" | 7.576 | 24.856 | ||||||
2-5/8" | 8.354 | 27.409 | ||||||
2-3/4" | 9.169 | 30.083 |
Worldwide Supply of Aluminum Round Bars
Russia, Bahrain, Cyprus, Egypt, Iran, Iraq, Israel, Jordan, Kuwait, Lebanon, Oman, Palestine, Qatar, Saudi Arabia, Syria, Turkey, United Arab Emirates (UAE), Yemen, United States of America (USA), Albania, Andorra, Austria, Belarus, Belgium, Bosnia and Herzegovina, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Montenegro, Netherlands, North Macedonia, Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Ukraine, United Kingdom, Vatican City.
